Products Description
1. Chassis Double-Layer Anti-Rust Primer: Electrostatic powder coating with secondary surface painting, anti-rust and
anti-peeling. The coating process includes degreasing, grinding, applying putty, epoxy zinc-rich primer (with 40% zinc content),and plastic spraying (electrostatic powder coating). The final coating is hard and durable.
2. Vehicle Wiring Control: Designed by the Tongji Automotive Research Institute, using national standard wires, waterproof plugs,flame-retardant wire tubes, and well-known electrical components. Wires are stripped by a wire stripping machine. The vehicle wiring control is designed and manufactured according to passenger vehicle standards.
3. Standard High-Pressure Water Gun: Easier to clean with a high-pressure water gun.
4. Water Tank Material: Made of imported PE (modified material), produced with rotational molding technology, more environmentally friendly and resistant to fading outdoors.
5. Ergonomic Design: Features an ergonomic handle, silicone waterproof skirt, and 304 stainless steel fastening screws throughout the vehicle.
6. Foot Pedal Lifting Brush and Suction Pad: Frees your hands, allowing you to control water flow without bending over.
|
Item |
Unit |
Parameter |
||
|
Model |
|
YF-GE240 |
||
|
Sucking Hose Dia |
mm |
110 |
||
|
Working Radius |
mm |
3200 |
||
|
Wheel Base |
mm |
1300 |
||
|
Wheel Tread |
mm |
750 |
||
|
Water Tank |
L |
60 |
||
|
Sewage Tank |
L |
240 |
||
|
Working Time |
H |
4 |
||
|
Power |
V/AH |
24/100 |
||
|
Walking Motor |
w |
2200 |
||
|
Vacuum Motor |
w |
1500 |
||
|
Water Pump |
Mpa |
0.9 |
||
|
Weight |
kg |
425 |
||
|
Dimension |
mm |
2450*950*1800 |
||
|
Filte Surface |
m2 |
9 |
||
